Features
Low Insertion Loss
Compact size
Ultra Stable and Highly Reliable
Extended Operating Temperature Available
Applications
Optical Add/Drop Multiplexing
Telecom networks
Metro networks
Broadband Networks
Performance Specifications
| Parameter | 4 Ch | 4+UPG | 8+UPG1 | 8+UPG2 | |
| Operating Wavelength (nm) | |||||
| Channel Wavelength (nm) | |||||
| UPG Port Wavelength Range(nm) | NA | TBD | 1260~ 1360 | 1260~ 1457 | |
| Channel Spacing(nm) | |||||
| Channel Passband (nm) | |||||
| Insertion Loss (dB)* | ≤0.8 | ≤0.8 | ≤1.4 | ≤1.7 | |
| Channel Ripple (dB) | |||||
| Isolation (dB) | Adjacent | ||||
| Non-adjacent | |||||
| UPG Isolation (dB) | NA | >15 | >15 | >15 | |
| Polarization Mode Dispersion (PS) | |||||
| Polarization Dependent Loss (dB) | |||||
| Directivity (dB) | |||||
| Return Loss(dB) | |||||
| Maximum Power Handling (mW) | |||||
| Operating Temperature (℃) | |||||
| Storage Temperature (℃) | |||||
| Fiber Type | |||||
| Connector | |||||
| Package dimension (mm) | |||||
Above specification are for device without connector.
Order Information
| Configuration | Channel No. | Pigtail Type | Fiber length | Declension(mm) | Connector |
|
CC=CCWDM | 40=4 Channel 41=4+UPG 80=8 Channel 81=8+UPG1 82=8+UPG2 …… |
0=250um 1=900um |
0=0.5m 1= 1m 2= 1.5m 3=others |
1= L55 x W45 xH6 2=L44 x W25 x H6 |
0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=others |
Type1:
Type 2:
